SimpleHome dimmer module for dimming halogen and fluorescent (CFL) lamps and dimmable LEDs, and for adjusting the intensity of electronic transformers. Power 300W. Dimmer operation controlled via a single or double button. Energy-saving motion detection function that allows the light intensity to be reduced when no motion is detected. DIN rail installation (2 modules). Dimensions: 35x90x58 mm. Maximum BUS current draw: 25 mA.
Technical data 20046851
- Output: 1 dimmer, 300 W
- Input: 1, for connecting a control button
- Loads: halogen lamps, compact fluorescent lamps (CFL), dimmable LEDs, electronic transformers
- Operation: with a single or double button
- Energy saving: light intensity reduced when no motion is detected
- Maximum BUS absorption: 25 mA
- Mounting: on DIN rail, 2 modules
- Dimensions: 35 × 90 × 58 mm
Product code: 20046851. See also in the Load Management Components category: SIMPLEHOME MODULE 5 INPUTS, 4 16A OUTPUTS ON DIN (5I4O16A) and SIMPLEHOME INTERFACE FOR DALI AND DMX PROTOCOLS.
