Vertical, customisable black capacitive push button using BUSing® technology, with 6 independent, fully programmable touch areas. It has LED indicators for each touch area, as well as a built-in temperature sensor with a concealed PI controller for maximum comfort and energy savings. It supports On/off, PWM or continuous control to manage the main and auxiliary cooling/heating systems.
Technical data ING-CD-V6N
- Vertical Design panel with 6 touch areas, black back casing and fixed glass with made-to-order print
- Supply: 12 Vdc from the BUS, consumption 20 mA at 12 Vdc
- Dimensions: 88 x 129 x 6 mm
- Flush in a universal box or directly on the wall
- Operating temperature: -10 °C to 55 °C
- Maximum BUS distance between devices: 300 m
The 6 inputs allow On/Off control of 6 electrical circuits, 3 blinds (2 outputs per blind, up and down) or 1 fan coil.
Product code: ING-CD-V6N. See also in the Multi-switches/Thermostats category: CUBIC ORIGEN VERT – 8 CH – BASIC – WHITE and CUBIC ORIGEN VERT – 6 CH – DESIGN – WHITE.
