White BUSing® technology thermostat with scroll (rotary touch control) for selecting the desired temperature and LED indicators for controlling an independent air conditioning zone. It has 8 fully configurable control areas, as well as dedicated touch areas for selecting the fan coil mode and speed. It includes a built-in temperature and humidity sensor, a concealed PI controller for maximum comfort, and dew point calculation. It supports On/off, PWM or continuous control for main and auxiliary heating/cooling systems, and it has a fully customisable front glass.
Technical data ING-CD-TLRB
- White back casing, Design version: fixed glass with a print of your choice
- 8 LED indicators for the touch areas and separate indicators for the thermostat
- Fan coil speed adjustable in 3 operating modes
- Measures temperature in the range 0 °C to 51 °C
- Current 35 mA at 12 Vdc
- Operation from -10 °C to 55 °C, storage from -30 °C to 60 °C
- Standards: EN 50090-2-2, UNE-EN 61000-6-3:2007, UNE-EN 61000-6-1:2007, UNE-EN 61010-1
The desired temperature is set with the scroll, while the 8 touch areas handle circuits, blinds or dimmers of the BUSing system.
Product code: ING-CD-TLRB. See also in the Multi-switches/Thermostats category: CUBIC-TLR ORIGEN VERTICAL – BASIC – WHITE and CUBIC-TLR+CO2 ORIGEN VERT – DESIGN – BLACK.
