White metal housing. EN50131 GRADE 2 certified. Equipped with:
- Open Frame power supply unit, PB battery charger, input 90-260 VAC / 50-60Hz, output 13.8 VDC / 5 A, EN50131-6 grade 2 certified
- 4 programmable outputs
- 2 auxiliary self-resetting outputs
- 8-pin dip-switch for addressing (maximum 8 power supplies) and speed selection
EN50131 grade 2 certification. 7Ah or 18Ah batteries. Anti-vandal. Dimensions (W x H x D): 315 x 440 x 95 mm.
Technical data VEDOPSU5A
- Input: 90–260 VAC, 50–60 Hz
- Output: 13.8 VDC, 5 A
- Power supply: open frame switching type, with lead-acid (Pb) battery charger
- Batteries: 7 Ah or 18 Ah
- BUS: two RS485, one for connection to the control panel and one for the opto-isolated bus isolator function
- Programmable outputs: 4 open collector, set by default to power supply status signalling
- Auxiliary power outputs: 2, each with a 1.5 A self-resetting fuse
- 8-pin dip-switch: addressing (up to 8 power supplies) and speed selection
- Housing: white metal, with anti-open and anti-tear tamper, dimensions 315 x 440 x 95 mm
- Certifications: housing to EN50131 Grade 2, power supply to EN50131-6 Grade 2
